The KUSAM-MECO High Voltage Insulation Resistance Tester KM Series is an advanced instrument designed for accurately measuring insulation resistance in high voltage electrical systems, equipment, and components. This tester is specifically tailored for applications where higher voltage levels are involved, such as power distribution networks, substations, electrical machinery, and industrial installations. Here are the key features and functionalities of the KUSAM-MECO High Voltage Insulation Resistance Tester KM Series:1. High Voltage Insulation Resistance Measurement: The KM Series tester is capable of measuring insulation resistance levels in megaohms (MΩ) or gigohms (GΩ) at high voltage levels. It can assess the integrity of insulation materials in high voltage cables, transformers, generators, switchgear, and other electrical assets.2. Wide Voltage Range: The tester offers a wide range of test voltages suitable for high voltage applications. It can apply test voltages ranging from several hundred volts (HV) to several kilovolts (kV), depending on the model and testing requirements.3. Digital Display: The tester features a digital display that shows insulation resistance readings in real-time, typically in units of megaohms (MΩ) or gigohms (GΩ). The display may include additional information such as test voltage, test duration, and measurement status indicators.4. Measurement Modes: KUSAM-MECO insulation resistance testers in the KM Series offer multiple measurement modes to suit different testing scenarios. These modes may include insulation resistance tests, polarization index (PI) tests, dielectric absorption ratio (DAR) tests, and timed testing modes for monitoring insulation behavior over time.5. Safety Features: The KM Series tester is equipped with built-in safety features to ensure safe testing procedures at high voltage levels. These features may include voltage lockout mechanisms, discharge circuits, audible and visual alarms for high voltage presence, and safety interlocks to prevent accidental energization.6. Data Logging and Storage: Some models of the KM Series tester come with data logging capabilities, allowing users to save and store measurement results for documentation and analysis. This feature is useful for tracking insulation resistance trends, identifying potential issues, and generating test reports.7. Portable Design: Despite its high voltage capabilities, the KM Series tester is designed to be portable and suitable for field use. It may come with a rugged housing, carrying handles, and protective features for safe transport and operation in different environments.Overall, the KUSAM-MECO High Voltage Insulation Resistance Tester KM Series provides reliable and accurate insulation resistance measurements in high voltage electrical systems. Its high voltage testing capabilities, digital display, measurement modes, safety features, data logging options, and portable design make it an essential tool for maintenance, testing, and quality assurance in high voltage applications.
Related Searches
Operating Temperature : -20 to 50 ℃
